Description
Main Features:
- This automatic industrial screen printing machine is controlled by PLC, which is very easy and has a high degree of automatism.
- This machine can be used with a UV dryer, UV & IR dryer to form the full automatic screen printing line.
- It’s broadly used in large-scale production environments.
- The automatic screen printing process can quickly achieve high-quality, consistent prints, making it a deal for large-scale production runs.
- The technology used in automatic industrial screen printing continues to evolve, with an advance in automation, materials, and printing techniques leading to efficiency, speed, and quality improvements.
Parameters:
| Model | TX-800SP | TX-1020SP | TX-1050SP |
|---|---|---|---|
| Max.printing size: | 800*600mm | 1020*720mm | 1050*750mm |
| Min.paper size : | 350*270mm | 560*350mm | 560*350mm |
| Max.paper size : | 800*590mm | 1020*710mm | 1050*720mm |
| Border: | < 10mm | < 10mm | < 10mm |
| Paper thickness : | 108-400g/m2 | 108-400g/m2 | 120-400g/m2 |
| Screen frame size: | 1070x1070mm | 1280x1140mm | 1300*1170mm |
| Max.printing speed: | 1000-3300pcs/h | 1000-3000pcs/h | 1000-3000pcs/h |
| Weight : | 4000kg | 5000kg | 5200kg |
| Power (kw) : | 3P4N 50/60HZ 380V 9kw |
3P4N 50/60HZ 380V 15kw |
3P4N 50/60HZ 380V 16.5kw |
| Dimension (LXWXH) | 4350*2580*1680mm | 4650*2800*1680mm | 4650*2800*1680mm |
